J7610D USB Microphone

J7610D USB Microphone

    14mm gold-plated capsule

    Cardioid

• Gold-plated capsule, 180 ° rejection ratio of more than 20dB, 135 ° rejection ratio of more than 18dB;

• Cardioid capsule with unique sound cavity to form a super polar pattern, which can effectively • prevent whistling

• Support multi-sampling rate/bit depth.

• High-precision digital circuitry, low thermal noise, stable performance.

• High compatibility, zero delay, clear voice.

• Pickup part of the design of universal rotation structure, can pick up different angles of the sound

• Shielded from RF interference.

  • Detail
  • Overview
  • Specifications



J7610D is a touch control USB digital microphone. It has a built-in driver-free sound card that is plug-and-play, and can be connected to a computer via a USB cable. It supports OTG connections to mobile devices such as smartphones and tablets. It is equipped with a high-quality gold-plated condenser capsule with 14mm diameter and high sensitivity. Can be realized through the touch panel mode selection, microphone gain adjustment, headphone volume adjustment, volume indication, a key mute function. J7610D is equipped with 3.5mm standard headphone jack, and the headphone output power can reach 60mW, with strong load capacity, synchronous monitoring, and real-time feedback. The standard Type-C interface is used for data transmission, which is highly versatile, flexible and multi-purpose, suitable for online teaching, courseware recording, online chatting, and game live streaming.

Capsule: 14mm gold-plated capsule

Polar Pattern: Cardioid

Frequency Response: 20-20,000Hz

Sensitivity: -15dBFS/Pa@1kHz

Microphone S/N: 67dB-A

Maximum SPL: 136dB (1%T.H.D.@1kHz,0dB SPL=2x10⁻⁵Pa)

Headphone power: 60mW @32Ω

Headphone S/N: 88.2dB-A

Sampling rate: 96KHz (support multi-sampling rate)

Bit depth: 24bit (support multi-bit depth)

Power supply: 5VDC

Weight: 295g

Dimensions: 25X65X205(mm)
